EMC Laboratory

The global shift of energy paradigm to carbon-free technologies has made the role of the power electronics technology in power conversion process more essential. Thereby, power electronics technology has found its way into many applications from renewable energy generation (i.e., wind power and solar power generation) down to Electrical Vehicle (EV) and even small appliances such as laptop chargers

EMC Laboratory

Although power electronic systems are a key enabler as a cross-functional technology in the energy conversion process, but due to their inherent switching behavior they exhibit disturbing electromagnetic noises. The pulse energy conversion of power electronic converters leads to serious Electromagnetic Interference (EMI), which cause the power grid to operate in an unpredictable and undesirable fashion. With the increase penetration of power electronics systems and advent of new Wide-Band Gap (WBG) devices capable of operating at high switching frequency with significant voltage and current transients, the complexity of modern power electronics systems will be elevated. Therefore, it highlights the importance of Electromagnetic Compatibility (EMC) in power electronics converters.

The EMC Laboratory mission is validating and improving EMC in power converter and hence accelerating deployment of modern power electronics systems in order to cope with current and future power grid. The laboratory is equipped with latest hardware and EMI measurement platforms in order to investigate EMC, harmonics, conducted and radiated emissions under different grid faults and loading conditions. The EMC Laboratory is designed to tackle real-world grid and power electronics challenges in close partnership with industry and research institutes at national and international levels.

The laboratory provides suitable research environment for PhD/Master courses and projects programmed in AAU. Every year the laboratory hosts many visiting researchers and guest PhDs around the world due to its powerful proof of concept platform.

FURTHER INFORMATION

FACILITIES

The laboratory is equipped with latest instrumentation and power converter setups including:

Grid Simulator [15 kVA/ 12kVA, unidirectional, three-phase/single-phase operation, simulating different grid-faults, generating background distortion]
EMI Receiver [Peak, QP and AV measurement updated with latest CISPR standards]
Screening room [for pre-compliance conducted emission test]
Broadband Antenna [for open area radiation measurement 30 – 1000 MHz]
Network analyzer [measuring parasitic and filter gain]
Near-field measurement probes
Motor drive system [up to 15 kW]

FEATURES & SERVICES

The EMC Laboratory provides research and development platform in order to investigate and develop new solutions for industry. This includes:

Pre-compliance EMC
Design and verification EMI filters performance
Analysis and improvement of power converter power quality
Verification and adaptation of new power converter concepts with upcoming IEC and CISPR standards [e.g., 2 – 150 kHz]
Evaluation of power electronics systems performance under harsh conditions (e.g., grid faults and loading profiles)
Design and optimization of application-oriented passive and active filtering solutions
Development of virtual-oriented EMI simulation
Input/output impedance measurement and modeling of power electronic converters
Developing application-oriented EMC design tool

Our research scientists have long-standing collaboration with many Danish and international companies and research institutes such as Fraunhofer IZM, Danfoss, Grundfos, FORCE Technology, NPC, Dansk Energi, Schneider Electric, PowerCon,Technical University of Dresden, The University of Queensland, University of Southern Denmark, Technical University of Denmark, KK-Electronics, Vestas.
